8625, Precision Reaction Torque Sensor

8625, Precision Reaction Torque Sensor

The 8625 torque sensor is designed for both static and dynamic measurements on non-rotating applications. It is particularly suitable for measurements of extremely small electrical actuating drives and micromechanical actuator elements.

Manufacturer : Burster Praezisionsmesstechnik Gmbh

Key Features

  • Reaction Torque Sensor
  • Round Shafts
  • Extremely Compact Design
  • Connection: 6- or 7-pin Plug Connector
  • Manufacturer Calibration for Left- and/or Right-Handed Torque (Option)

Specifications

TypeReaction
Full Scale0.005 Nm
0.01 Nm
0.02 Nm
0.05 Nm
0.1 Nm
0.2 Nm
0.5 Nm
1 Nm
2 Nm
5 Nm
2000 Nm
5000 Nm
Output0.5 mV/V
0.8 mV/V
Precision±0.12 % FS
Excitation2 V - 12 V DC
Drive SideRound Shaft
Test SideRound Shaft
IP RatingIP50
Min Temperature-15 °C
Max Temperature55 °C

Downloads

8625 High Precision Torque SensorDatasheet
8625-4005 CAD DrawingDrawings
8625-4010 CAD DrawingDrawings
8625-4020 CAD DrawingDrawings
8625-4050 CAD DrawingDrawings
8625-4100 CAD DrawingDrawings
8625-4200 CAD DrawingDrawings
8625-4500 CAD DrawingDrawings
8625-5001 CAD DrawingDrawings
8625-5002 CAD DrawingDrawings
8625-5005 CAD DrawingDrawings
8625-5010 CAD DrawingDrawings
8625-5020 CAD DrawingDrawings
8625-5050 CAD DrawingDrawings
8625-5100 CAD DrawingDrawings
8625-5200 CAD DrawingDrawings
8625-5500 CAD DrawingDrawings
8625-6001 CAD DrawingDrawings
8625-6002 CAD DrawingDrawings
8625-6005 CAD DrawingDrawings
